NV-900( new product)
4.5-22.5 x 40 Digital Night Vision Binocular wide dynamic range take 5mp Photo & 720p Video with 4” Display UP to 400m





4.5-22.5 x 40 Digital Night Vision Binocular wide dynamic range take 5mp Photo & 720p Video with 4Display  UP to 400m


Model NoNV-900

Patent No004596146-0001EURO201830003244.4China

           US D850507S(USA)


Digital Night Vision Binocular Uses:

HuntingScouting game

Security and surveillance

Camping fun/exploring caves

Nighttime navigation

Night fishing and boating

Wildlife observation

Search and rescue




Time lapse Function:YES

GPS ID stamp on the picture or video:YES

wide dynamic range  UP TO 4displayWide field of view

Outstanding optical clarity, high performance night vision

1/3CMOS vs image-intensifier tube

Build In  2TFT , View Large LCD Screen UP TO 4display

Resolution of Screen:640*480

TF card: up to 32G(no included)

Adjustable eyepiece

Powerful infrared spotlight

1300ft /400M viewing range

Magnification(optical): 4.5

Objective Aperture:φ40mm

Exit Pupil Distance:46.2mm

Digital Zoom 5

Field of View: 9°

F for Objective lensF=1.3


Infrared Illuminator: 850NM 3W Infrared LED

★JPEG: 2592*1944,1600*1200,640*480

★Video:1280*720640*480@30FPS with sound

Observing Distance(Low Light Environment):2m

Time stamp:Date and time GPS on picture and video

★Observing Distance(Full Dark Environment): 1300ft /400M

★Language:English, French,German,Italian,Japanese & Russian,Spanish,Czechen,Polish

Working Power Voltage:4.5-6V or 6V Power bank

Rechargeable Battery:  8 *AA,lithium,alkaline or NI-MH Battery

Up to 14 hours runtime without the use of infrared illuminator.

Up to 10 hour with IR illuminator on.

Built-in 1 tripod mountable:YES1/4 Tripod interface

TV Out :Device be a live Infrared surveillance camera connecting TV with TV cable

USB: Micro USB2.0

AV supporting:NTSC/PAL

Water Resistance StandardIPX4

Operating Temperature Range:-30-55°(Storage temperature: -40°C - 70°C)

L / W / H: 20516988 mm

Digital night vision +Wrist Strap Weight: 0.90kg

Digital night vision Weight+ 8*AA battery):1100g



User's Manual  *1

Cleaning Cloth  *1

Pouch  *1

USB Cable *1

TV Cable *1

Neck Strap *1

Lens cap*1

Wrist Strap*2



Digital night vision: 230 x 155 x 65mm  [L / W / H]

Digital night vision Weight: 760g


Net wight:14.5kg Gross weight:15.4kg

One gift box: 290 x 210 x 100mm

Dimensions: 540 x 445x 306mm [L/ W / H]
